RT9129HRW Racing Seat

Brand: Racetech Manufacturing
Code: RT9129HRW-016
Availability: In Stock
£6,299.99 Ex VAT

Available Options

* Size:

Add Ram Air Kit:


Add Net Guide Kit:

+ -
  Add to Compare
Description

Surpassing the stringent demands of the FIA 8862-2009 Advanced Racing Seat standard, the 129 series is Racetech’s no compromise professional motorsport seat range. Used by the majority of British Touring Car (BTCC) teams in 2016 and 2017, there is none better when it comes to safety and comfort. This is our lightweight Kevlar/carbon version, one of the lightest seats in the world to achieve 8862-2009 homologation!
CAD models are available on request. Side (RTB1009M) and back (RTB1006B/W) mounting brackets are included.

* To comply with FIA 8862-2009, the 129 series seats must be back-mounted to the rollcage at shoulder level. Back-mounting improves seat strength and stability during an impact, increases driver 'feel' and reduces driver fatigue, see the explanatory video here.


Dimensions and Weights:

Model Material FIA 8862 A B C D E F G Mount Width Shell Weight Total Weight
RT9129HRW Kevlar/carbon Yes 62 58 37 46 47 92 62 40 8.7 10.2
RT9129THR Kevlar/carbon Yes 62 64 37 46 47 98 68 40 9.0 10.5
RT9129WHR Kevlar/carbon Yes 67 58 41 50 47 92 62 44 9.0 10.5
RT9129WTHRL Kevlar/carbon Yes 67 64 41 50 47 93 68 44 8.1 9.6
            dimensions in cm   weights in kg

Dimensions Key


All Racetech seats are proudly manufactured in Wellington, New Zealand.

Specification
Application
Common Applications International circuit or rally where extreme strength and FIA 8862-2009 homologation is important
Stock Colour / Material
Gel-coat Transparent self-finish
Seat Cover Black fire-retardant fabric
Wear Patches Grey suede leather
Technical
FIA Homologation Complies with the latest FIA 8862-2009 regulations
Shell Construction Kevlar/carbon
Shell Weight 8.1 - 9.0kg (dependent on size)
Side Mount Hole Centres 295mm
Back Mount Hole Centres 250mm
Bolt Torque (Zinc) 30Nm / 22 ft lb
Design
Head Restraint Integrated head restraint
HANS Compatible Yes
Harness Compatibility Up to 6-point harness
Large Harness Guides Yes
Air Ducting Yes - vented to the driver's lower back
Back-mount Compatible Yes - back mounting required for FIA homologation
